One Product Introduction:

This product is suitable for low-temperature freezing testing of materials.

1. The product adopts a single-stage refrigeration cycle, uses a fully enclosed unit, matches reasonably, and has a fast cooling speed; The box type is a horizontal structure; The box adopts a polyurethane foam insulation layer with good insulation performance.

2. The inner lining of the box is made of anti-corrosion board, which has good cold conductivity and beautiful appearance.

3. This product is equipped with a computer temperature controller that automatically controls the temperature inside the box. Box temperature digital display, High temperature control accuracy,

Stable and reliable performance, easy to operate.

4. The electronic control system is equipped with box temperature tracking display and over temperature code light alarm display function.

5. The compressor runs smoothly with low noise, ensuring a comfortable working environment.

2、 Product specifications and parameters:

1. Studio volume specifications: 100 liters, 225 liters, 608 liters, 1000 liters (customizable)

2. Product style: divided into vertical and horizontal (customizable)

3. Temperature range: -50 ℃- 70 ℃- 100 ℃- 120 ℃- 150℃

7. Input power: 2KW~20KW

8. Net weight: 70kg;

9. Noise: not exceeding 70dB (A);

3、 Box and equipment:

1. Inner box material: seamless welding of medical grade 304 stainless steel plate

2. Outer box material: galvanized steel plate with baked paint treatment

3. Rigid polyurethane foam insulation material

4. Measurement device

This product is equipped with a temperature controller that automatically controls the temperature and humidity inside the box. Box temperature digital display, temperature control accuracy

High performance, stable and reliable, easy to operate, temperature and time can be freely set

5. Freezing and control system

Refrigerator air cooling: original imported single-stage fully enclosed compressor unit

Environmentally friendly refrigerant

Multi stage heat dissipation plate cooler for evaporator

Temperature sensor: PT100 type thermistor (dry bulb)
